Service Telephone:86-755-83294757
Trade Name:Motor/Motion/Ignition Controllers and Drivers
Brand:ST
Particular Year:16+
Package:LQPF64
Delivery Date:New and Original
Stock: 6440pcs
The L99DZ100GPTR is a gate zone system integrated circuit that provides an electronic control module with enhanced power management features, including various standby modes and LIN and HS CAN physical communication layers.
The L99DZ100GPTR device's two low dropout regulators power external peripheral loads such as system microcontrollers and sensors, and provide enhanced system standby functionality with programmable local and remote wake-up features. In addition, eight high-side drivers for LEDs and two high-side drivers for lamps increase the level of system integration.
The H-bridge configuration can drive up to 5 DC motors and 4 external MOS transistors. An additional gate driver controls an external MOSFET in the high-side configuration to power resistive loads connected to GND, such as mirror heaters. Electrochromic mirror glass can be controlled using the integrated SPI driver module and external MOS transistors. All outputs are SC-protected and feature open-load diagnostics.
L99DZ100GPTR Product Attributes
Manufacturer: STMicroelectronics
Product Category: Motor/Motion/Ignition Controllers and Drivers
Type: Automotive
Output Current: 7.5 A
Operating supply current: 11 mA
Minimum operating temperature: - 40 C
Maximum operating temperature: + 175 C
Mounting style: SMD/SMT
Package / Case: LQFP-64
Qualification: AEC-Q100
Humidity Sensitivity: Yes
Series: L99DZ100GP
Supply Voltage - Max: 28 V
Supply Voltage - Min: 6 V
Applications
Door zone applications
Model
Brand
Package
Quantity
Describe
ST
64-LQFP
3222
Automotive Front Door device with LIN and HS-CAN providing Dual H-bridge driving
Qorvo
TQFN-48
1000
Motor/Motion/Ignition Controller and Driver 48V ChargePumpMotor ContDriver 10.8V-24V
Qorvo
QFN-40
1000
Motor/Motion/Ignition Controllers and Drivers 40V/20W Motor Controller/Driver
