The ATSAM4S2CA-AU is a high performance 32-bit ARM Cortex-M4 microcontroller belonging to the SAM4S family.

ATSAM4S2CA-AU Product Features

High-performance processor: Based on ARM Cortex-M4 core, it can operate up to 120MHz, providing powerful processing capability.

Storage capacity: Built-in 128KB flash memory and 64KB RAM to meet the storage requirements of complex applications.

Rich peripheral interfaces: Supporting a variety of communication interfaces, including I2C, SPI, UART, USART, USB, etc., the device also features a 16-channel 12-bit ADC and 2-channel 12-bit DAC, which are suitable for various analogue signal processing scenarios.

Low-power design: Operating voltage range from 1.62V to 3.6V, suitable for battery-powered portable devices.

High Reliability: Various protection functions, such as under-voltage detection, reset function, watchdog timer, etc., ensure the stable operation of the system.

ATSAM4S2CA-AU Product Attributes

Product Category: ARM Microcontrollers - MCUs

Series: SAM4S

Mounting Style: SMD/SMT

Package / Case: LQFP-100

Core: ARM Cortex M4

Program memory size: 128 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 120 MHz

Number of inputs/outputs: 79 I/Os

Data RAM size: 64 kB

Supply voltage - min: 1.08 V

Supply voltage - max: 1.32 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Analogue supply voltage: 1.2 V

DAC resolution: 12 bit

Data Ram type: SRAM

I/O voltage: 3.3 V

Interface type: I2C, SPI, UART, USART

Number of ADC channels: 16 Channel

Number of Timers/Counters: 6 Timer

Processor family: SAM4S

ATSAM4S2CA-AU Application Areas

Industrial Control: Suitable for motor drive, sensor data acquisition and processing, industrial automation equipment, etc. Its powerful timer and ADC conversion function can accurately control and monitor industrial processes.

Consumer Electronics: Suitable for smart home appliances, portable audio devices, etc. Its low-power design helps to extend battery life, and its rich peripheral interfaces can realise a variety of functions.

Medical devices: Used in portable medical instruments, health monitoring devices, etc. Low power consumption and high reliability ensure stable operation in critical applications.
