For picture reference, please see the specifications
< >

Commodity Model:88W8987-A2-EAHE

Trade Name:WiFi Bluetooth

Brand:NXP

Particular Year:22+

Package:eWLP-83

Delivery Date:New and Original

Stock: 6000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
88W8987-A2-EAHE
Package
eWLP-83
Describe
2.4/5 GHz Dual-Band 1x1 Wi-Fi® 5 (802.11ac) + Bluetooth® 5.2 Solution

Product Description

The 88W8987-A2-EAHE is a highly integrated Wi-Fi 5 (802.11ac) and Bluetooth 5.2 single-chip solution in an 83-WFBGA (WLCSP) package for high-performance wireless communication applications such as smart home, Internet of Things (IoT), automotive electronics and industrial equipment.


Core Features (88W8987-A2-EAHE)

Dual-band Wi-Fi 5 (802.11ac Wave 2)

Supports 2.4GHz & 5GHz Dual Band

MU-MIMO (Multi-User Multiple-Input Multiple-Output) to improve network throughput

Data transfer rate up to 433Mbps (MCS9)

Supports WPA3 encryption for enhanced security

Bluetooth 5.2 support

Compatible with Bluetooth Classic + BLE (Low Power Bluetooth)

Supports LE Audio, mesh networking

Optimised Wi-Fi/Bluetooth coexistence to reduce interference

Rich host interface

SDIO 3.0 (Wi-Fi control)

High-speed UART (Bluetooth communication)

PCM (audio transmission)

21 GPIOs for flexible expansion

Low power consumption design

Receive current: 38mA~82mA

Transmit current: 79mA~145mA

Multi-level power management to optimise energy efficiency

Industrial Grade Reliability

Operating temperature: -30°C ~ +85°C

AEC-Q100 compliant (some models for automotive electronics)

Resistant to EMI/ESD interference for harsh environments


Typical Applications (88W8987-A2-EAHE)

Smart home: Wi-Fi gateway, smart speakers

Automotive electronics: in-vehicle infotainment (IVI), T-Box

Industrial IoT: wireless sensors, remote monitoring devices

Consumer Electronics: AR/VR devices, game controllers


Parameters (88W8987-A2-EAHE)

Operating Frequency: 2.4GHz, 5GHz

Wi-Fi standard: 802.11ac (Wave 2)

Bluetooth version: 5.2

Output power: 22dBm

Supply Voltage: 1.1V, 1.8V, 2.2V

Receive Current: 38mA~82mA

Transmit Current: 79mA~145mA
