The QorIQ® P1 platform family of P1025NSN5DFB communications processors offers a rich set of integrated features and superior performance for a wide range of applications in the networking, telecom, defence, and industrial control markets. The P1025NSN5DFB processor features a low-power 45nm process and is available in both single and dual core solutions running at 400 MHz and 667 MHz, with advanced security features, QUICC Engine®, and rich interfaces.

Features of P1025NSN5DFB

Kernel Complex

Two (P1025) high-performance Power Architecture® e500 cores with 32 KB L1 cache running at up to 667 MHz

256 KB L2 cache with ECC, also configurable as SRAM and buffer memory

Network Components

Three 10/100/1000 enhanced 3-speed Ethernet controllers (eTSEC)

Two SGMII interfaces

IEEE® 1588 support

QUICC Engine® module support:

UTOPIA-L2

Four T1/E1/HDLCs

Two 10/100 Ethernet

Accelerator and memory control

DDR3 32-bit memory controller with ECC support

Built-in security engine

Supported protocols include SNOW, ARC4, 3DES, AES, RSA/ECC, RNG, single pass SSL/TLS, Kasumi

XOR acceleration

Basic peripherals and interconnections

4-channel SERDES up to 3.125 GHz, inter-controller multiplexing

Two PCI Express® Gen1.0 interface controllers

Two USB 2.0 controllers

Enhanced Local Bus Controller (eLBC)

TDM

eSDHC

Dual I²C, DUART, PIC, DMA, General Purpose IOs

Other Features

PROFIBUS support

Long-term availability programme for NXP® products

561-pin 31x31 mm TePBGA package

QorIQ® P1 Platform Family P1025NSN5DFB Applications

Industrial control

Front view cameras

Automotive and industrial vision systems

Surround vision

Power Meters

Energy Gateways

General Avionics

Automotive Electronics

Intelligent Roadside Communication Units

Automotive High Performance Computing

Driver Monitoring Systems (DMS) and Occupant Monitoring Systems

Consumer Electronics

Personal/Consumer Electronics NAS
