The S9KEAZ128AMLH is a 32-bit ARM Cortex-M0+ core microcontroller (MCU), part of the Kinetis® EA family, designed for automotive electronics, industrial control and high-reliability embedded systems. Packaged in LQFP-64 with 128KB of Flash memory and 16KB of SRAM, the MCUs run at up to 48MHz and support a wide voltage range of 2.7V to 5.5V, making them ideal for high-performance, low-power applications in harsh environments.

Core Features (S9KEAZ128AMLH)

High performance Cortex-M0+ core

32-bit RISC architecture, single-cycle I/O access

Up to 48MHz main frequency, supports single-cycle 32×32 multiplier

Harvard architecture for optimised instruction execution efficiency

Mass storage

128KB Flash (with ECC checksum)

16KB SRAM (with hardware CRC check)

Rich Peripheral Interface

12-bit ADC (16-channel, 1MSPS)

Analogue Comparator (ACMP) + 6-bit DAC

PWM Timer, RTC, Watchdog (WDT)

Communication interfaces: SPI, I2C, UART, LIN, CAN

71 GPIOs with external interrupt (IRQ) support

Low power consumption design

Multiple power saving modes (standby, shutdown, deep sleep)

Standby current as low as 0.5μA for battery-powered devices

Automotive-grade reliability

AEC-Q100 certified for wide temperature range of -40°C ~ +125°C

Excellent EMC/ESD immunity, low radiation design

Power-down detection (LVD) + temperature monitoring for enhanced system stability

Typical Applications (S9KEAZ128AMLH)

Automotive electronics: body control (BCM), sensor nodes, LIN/CAN communication

Industrial control: PLC, motor drive, HMI human-machine interface

Smart home: IoT gateway, security equipment

Medical equipment: portable monitoring instruments
