The QS3VH253QG8 HotSwitch Dual 4:1 Multiplexer/Demultiplexer is a high-bandwidth bus switch with extremely low on-resistance and propagation delays through the switch of less than 250 ps. Near-zero propagation delays, high shutdown impedance, and overvoltage tolerance make the QS3VH253QG8 ideal for high-performance communications applications. The QS3VH253QG8 operates over the -40 °C to +85 °C temperature range.

QS3VH253QG8 Features

N-channel FET switch with no parasitic diode at VCC

Isolation under power-down conditions

No direct current to VCC or GND

5V withstanding in off and on condition

5V Tolerance I/O

Low RON - 4Ω typical

Flat RON characteristics over operating range

Rail-to-rail switching 0V to 5V

Bi-directional data flow with near-zero latency: no additional ground bounce

Excellent RON matching between channels

VCC operating voltage: 2.3V to 3.6V

High bandwidth - up to 500MHz

LVTTL-compatible control inputs

Downswing clamping diodes on all switch and control inputs

Low I/O capacitance, 4pF typical

16-pin QSOP package

QS3VH253QG8 Specifications

Logic family: LVTTL

Number of input lines: 4 Input

Number of output lines: 1 Output

Package / Case: QSOP-16

Number of bits: 8 bit

Propagation delay time: 0.2 ns

Supply voltage - min: 2.3 V

Supply voltage - max: 3.6 V

Mounting style: SMD/SMT

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

QS3VH253QG8 Applications:

Hot Swap

Multiplexing/Demultiplexing

Low distortion analogue switching

Replaces mechanical relays

ATM 25/155 Switching
