The LPC1778FBD144 is an ARM Cortex-M3 based microcontroller for embedded applications requiring high integration and low power consumption.

The ARM Cortex-M3 is a next-generation core that delivers more performance than ARM7 at the same clock frequency and features other system enhancements such as modern debugging capabilities and a higher level of support block integration.The ARM Cortex-M3 CPUs incorporate a 3-stage pipeline with a Harvard architecture and separate local instruction and data buses, as well as a slightly lower-performance third bus for peripherals.The ARM Cortex-M3 CPUs incorporate a 3-stage pipeline with Harvard architecture and separate local instruction and data buses and a slightly lower-performance third bus for peripherals. The ARM Cortex-M3 CPU also includes an internal prefetch unit that supports speculative branching.

LPC1778FBD144 -- ARM® Cortex®-M3 LPC17xx Microcontroller IC 32-bit Single Core 120MHz 512KB (512K x 8) Flash 144-LQFP (20x20)

Product Attributes

Core Processor: ARM® Cortex®-M3

Core specification: 32-bit single-core

Speed: 120MHz

Connectivity: CANbus, EBI/EMI, Ethernet, I2C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG

Peripherals: Power Down Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT

Number of I/O: 109

Program memory capacity: 512KB (512K x 8)

Programme memory type: Flash

EEPROM Size: 4K x 8

RAM Size: 96K x 8

Voltage - Supply (Vcc/Vdd): 2.4V ~ 3.6V

Data Converter: A/D 8x12b; D/A 1x10b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 85°C (TA)

Mounting Type: Surface Mount

Supplier Device Package: 144-LQFP (20x20)

Package/Housing: 144-LQFP
