WFI32E02UC-I is a low power Wi-Fi MCU module with 200 MHz, 1MB Flash, 60 GPIO and a global-regulatory certified U.FL antenna connector. WFI32 is specially designed for industrial IoT applications.

Feature

On-Board FEM/PA to Meet the TX Power Requirements

Maximum 20.5 dBm TX Power in 802.11b Mode

ingle-band 2.4 GHz b/g/n

WPA/WPA2/WPA3 Personal, TLS, SSL security protocols

Support for AP, STA, SoftAP

Optional full featured hardware crypto accelerator

U.FL antenna connector

200 MHz, MIPS32 M-Class microprocessor core

1 MB embedded flash, 256 KB SRAM (program and data), 64 KB data buffer

18 CVD touch input

3 x UART, 2 x I2C, 2 x SPI, SQI

60 GPIOs

High performance peripheral set including full-speed USB, CAN, CAN-FD, 10/100 MAC, and high accuracy 12-bit dual ADC with 20 channels
