ATWILC1000-MR110UB - SPI/SDIO to Wi-Fi® Link Controller Module

Product Overviews

ATWILC1000-MR110UB is an IEEE 802.11 b/g/n IoT link controller module. The ATWILC1000 supports single stream 1x1 802.11n mode providing tested throughput of up to 46 Mbps UDP & 28 Mbps TCP/IP. The ATWILC1000 features a fully integrated Power Amplifier, LNA, Switch and Power Management.

Product Features

• IEEE 802.1 b/g/n 20 MHz (1x1) Solution

• Single Spatial Stream in 2.4 GHz ISM Band

• Integrated PA and T/R Switch

• Superior Sensitivity and Range via Advanced PHY Signal Processing

• Advanced Equalization and Channel Estimation

• Advanced Carrier and Timing Synchronization

• Wi-Fi Direct®and Soft-AP Support

• Supports IEEE 802.11 WEP, WPA, WPA2 and WPA2-Enterprise Security

• Superior MAC Throughput via Hardware Accelerated Two-Level A-MSDU/A-MPDU Frame Aggregation and Block Acknowledgment

• On-Chip Memory Management Engine to Reduce Host Load

• SPI and SDIO Host Interfaces

• Operating Conditions:

– Operating temperature: −40°C to +85°C

– Input/Output supply voltage(VDDIO): 1.62V to 3.6V

– Power supply (VBATT): 3.0V to 4.2V

• Power Save Modes:

– <1 μA Deep Power-Down mode typical at 3.3V I/O

– 380 μA Doze mode with chip settings preserved (used for beacon monitoring)

– On-chip low-power sleep oscillator

– Fast host wake up from Doze mode by a pin or host I/O transaction
