The MSCSM120HM31TBL2NG device is a Silicon Carbide (SiC) MOSFET power module with 1200V phase pin voltage and 79A current. It features a SiC power MOSFET with low RDS (conduction), high temperature performance, Kelvin source, and easy drive. Low stray inductance, high efficiency converter, excellent performance at high frequency operation, stable temperature characteristics.

Product Characteristics

Technology: Silicon Carbide (SiC)

Configuration: 4 N-Channel (Full Bridge)

Drain-to-source voltage (Vdss): 1200 V (1.2 kV)

Current at 25°C - Continuous Drain (Id): 79A

Switching Resistance (Max) at Different Id, Vgs: 31 mOhm @ 40A, 20V

Vgs(th) at Different Id (Max): 2.8V @ 3mA

Gate charge (Qg) at Vgs (max): 232nC @ 20V

Input Capacitance (Ciss) at Vds (Max): 3020pF @ 1000V 3020pF @ 1000V

Power - Max: 310W

Operating Temperature: -55°C ~ 175°C (TJ)

Mounting Type: Chassis Mount

Packaging/Enclosure: Module

Applications

●High reliability power systems

●High efficiency AC/DC and DC/AC converters

●Motor control
