Trade Name:Ethernet PHY
Brand:BROADCOM
Particular Year:24+
Package:BGA-485
Delivery Date:New and Original
Stock: 1000pcs
The Broadcom® BCM88750B0KFSBLG is a single-chip, eight-lane, ultra-low power, ultra-low latency PHY that integrates retimer and equalizer to support active cable applications. The BCM88750B0KFSBLG is capable of equalizing 22 dB of loss on both the client-side and line-side interfaces. Each lane is capable of multiple data rates, including 106.25 Gb/s.
The on-chip clock synthesis is performed by a low-cost 312.5-MHz reference clock through high-frequency, low jitter phase-locked loops (PLLs).
The BCM88750B0KFSBLG is fabricated in low-power 7-nm CMOS technology and is available in a 12 mm × 12 mm, 0.5-mm pitch, 485-ball BGA, RoHS-compliant package.
Features Of BCM88750B0KFSBLG
• Single chip for 800GbE active copper cable QSFP112
• Auto-negotiation and link training on the line side
• VSR+ capable up to 22-dB loss
• Continuous auto-adaptive equalizers
• Integrated AC-coupling capacitors on the host-side and line-side receiver
• Line-side and host-side loopbacks
• PRBS generators and checkers
• Low-power 7-nm CMOS design
• Supports QSFP112 copper modules
• Power consumption <6W
Applications Of BCM88750B0KFSBLG
• Supports 800G active electrical cable and 800G active copper cable applications
