The BMM150 is a low-power, low-noise, three-axis digital geomagnetic sensor that is perfectly suited for compass applications. Based on Bosch's proprietary FlipCore technology, the sensor is small and lightweight, making it particularly well suited to support precise heading for UAVs.

Technical specifications

Technology: FlipCore, Hall effect

Axes: X, Y, Z

Output Type: I2C, SPI

Sensing Range: ±1.3mT (X, Y), ±2.5mT (Z)

Voltage - Supply: 1.62V ~ 3.6V

Current - Supply (Max): 20mA

Resolution: 13 b

Bandwidth: 10Hz

Operating Temperature: -40°C ~ 85°C

Supplier Device Package: 12-WLCSP (1.56x1.56)

Mounting Type: Surface Mount

Package/Housing: 12-UFBGA, WLCSP

Typical Applications

Magnetic heading information

Tilt-compensated electronic compass map rotation, navigation and augmented reality

Gyroscope calibration for mobile devices in 9-DoF applications

Indoor navigation, e.g. combined accelerometer step counting

Gaming
