DLP5532AFYSQ1 - 0.55-Inch 1.3-Megapixel DMD for Automotive Display

Product Description

DLP5532AFYSQ1 automotive DMD, combined with the DLPC230-Q1 DMD controller and TPS99000- Q1 system management and illumination controller, provides the capability to achieve a high performance automotive window display when illuminated onto a special window film surface. The 2:1 aspect ratio supports very wide aspect ratio designs, and the 1.3 million native pixels enables high resolution content.

Product Features

0.55-inch diagonal micromirror array

– 7.6-μm micromirror pitch

– ±12° micromirror tilt angle (relative to flat state)

– Bottom illumination for optimal efficiency and optical engine size

– Supports 1152 × 576 input resolution

– Up to 2304 x 1152 resolution with external GPU based diamond pre-processing

– Compatible with LED or laser illumination

600MHz sub-LVDS DMD interface for low power and emission

10kHz DMD refresh rate over temperature extremes

Built-in self test of DMD memory cells

Image performance optimized for window displays and other interior displays

Applications

Window display for front, side, and rear vehicle windows

Interior ceiling projectors
