The AM4378BZDN100 high performance processor is based on the ARM Cortex-A9 core. The processor is enhanced by 3D graphics acceleration for rich graphical user interfaces and a co-processor for deterministic real-time processing (including industrial communication protocols such as EtherCAT, PROFIBUS, EnDat, etc.). The device supports the High-Level Operating System (HLOS). Linux-based® is available free of charge from TI. Additional HLOS is available from TI's design network and ecosystem partners.

Product Attributes

Core processor: ARM® Cortex®-A9

Number of Cores/Bus Width: 1 core, 32-bit

Speed: 1.0 GHz

Co-processor/DSP: Multimedia; NEON™ SIMD

RAM Controller: LPDDR2, DDR3, DDR3L

Graphics Acceleration: Yes

Display and Interface Controller: TSC, WXGA

Ethernet: 10/100/1000Mbps (2)

USB: USB 2.0 + PHY (2)

Voltage - I/O: 1.8V, 3.3V

Operating Temperature: 0°C ~ 90°C (TJ)

Security Features: Password Accelerator

Mounting Type: Surface Mount

Package/Housing: 491-LFBGA

Supplier Device Package: 491-NFBGA (17x17)

Additional Interfaces: CAN, HDQ/1-Wire, I²C, McASP, MMC/SD/SDIO, QSPI, SPI, SD/SDIO, UART

Applications

● Patient monitoring

● Navigation equipment

● Industrial automation

● Portable data terminals

● Barcode scanners

● Point-of-service

● Portable mobile radios

● Test and measurement
