ZSSC3240CI3W is a sensor signal conditioning IC for highly accurate amplification, digitization, and sensor-specific correction of resistive sensor signals.

Feature

Digital communication and calibration interfaces

SPI up to 10MHz

I2C (Standard, Fast, and High-Speed Mode)

One-wire-interface (OWI), up to 100kBit/s

Accommodates nearly all resistive bridge sensor types (signal spans from 1mV/V up to 500mV/V)

Supports different sensor element configurations

Resistive bridge or half-bridge

Resistive divider string

Voltage source

On-chip temperature sensor

External temperature sensing supported, e.g. sensor-bridge as temperature detector, external diode, etc.

Programmable 16-bit digital-to-analog-converter and output

(0V to 1V) or (0V to 5V) absolute voltage output

VDD-ratiometric voltage output

4mA to 20mA current-loop output supported

0V to 10V absolute-voltage output supported

On-chip voltage regulators for sensor supply, and IC operation

Support for VDD regulation by external JFET

24-bit analog-to-digital converter and 26 bits digital-signal-conditioning math core

Reprogrammable, nonvolatile memory (NVM)

Programmable measurement scheduler for continuous sensing applications, with optimized balance of

Output update rate

Sensor-signal-conditioning accuracy

Self-diagnostic coverage and system safety

On-chip diagnostics:

Sensor connection

Broken-chip-check / chipping-check

Memory integrity

Application

LoRaWAN®-Based Gas Meter

IO-Link Device Solutions

Sensor Signal Conditioner to Linearize Results

Embedded Programmable Logic Controller (PLC) for Industrial Use

IO-Link Slave Sensor Solution

Wireless Weight Scale

All-in-One Smart Pressure Cooking Pot
