FF33MR12W1M1HP IGBT modules (with CoolSiC™ MOSFETs) have very low stray inductance and excellent efficiency, resulting in higher frequencies, higher power densities, and lower cooling requirements. 1200V, 8mΩ half-bridge modules feature integrated NTC temperature sensors and PressFIT contact technology. xHP_B11 models are available with thermal interface materials. . This family of devices features recommended gate drive voltage ranges of 0 to 5V and +15V to +18V, maximum gate-source voltages of +23V or -10V, and options for 17mΩ or 33mΩ drain-source resistance. Integrated mounting clips ensure a secure installation.

Features

● Best-in-class package with dimensions of 62.8mm x 33.8mm x 12mm (LxWxH)

● Combines advanced WBG materials with a simple module package

● Very low module stray inductance

● Wide RBSOA

● 1200V CoolSiC MOSFETs with enhanced first generation trench technology

● Extended recommended gate drive voltage window: 0 to 5V and +15V to +18V

● Extended maximum gate-source voltage: +23V and -10V

● Drain-source on-resistance options: 17mΩ or 33mΩ

Applications

● High frequency switching applications

● DC/DC converters

● UPS systems

● Motor drives
