For picture reference, please see the specifications
< >

Commodity Model:CYBT-333047-02

Trade Name:CYBT-333047-02

Data Manual:CYBT-333047-02.pdf

Brand:INFINEON

Particular Year:23+

Package:24-SMD Module

Delivery Date:New and Original

Stock: 1000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
INFINEON
Model
CYBT-333047-02
Package
24-SMD Module
Describe
Bluetooth v5.0 Transceiver Module 2.402GHz ~ 2.48GHz Antenna Not Included, U.FL Surface Mount

Product Description

CYBT-333047-02 is a fully integrated Bluetooth Smart Ready wireless module. It supports peripheral functions (ADC and PWM), UART, I2C, and SPI communication, and a PCM/I2S audio interface.


Product Attributes

RF Family/Standard: Bluetooth

Protocol: Bluetooth v5.0

Modulation: 8DPSK, DQPSK, GFSK

Frequency: 2.402GHz ~ 2.48GHz

Data Rate: 4Mbps

Power - Output: 12dBm

Sensitivity: -96.5dBm

Serial Interfaces: ADC, I²C, I²S, PCM, PWM, SPI, UART

Antenna Type: Antenna Not Included, U.FL

Utilized IC / Part-

Memory Size: 512kB Flash, 352kB RAM, 848kB ROM

Voltage - Supply: 2.3V ~ 3.6V

Current - Receiving: 26.4mA

Current - Transmitting: 52.5mA ~ 60.3mA

Mounting Type: Surface Mount

Operating Temperature: -30°C ~ 85°C (TA)

Package / Case: 24-SMD Module


Product Features

512-KB on-module serial flash memory

Up to 11 GPIOs

Temperature range: –30 °C to +85 °C

Arm Cortex-M3 32-bit processor

Serial Communications Interface compatible with I2C slaves

SPI support for both master and slave modes

HCI interface through UART

PCM/I2S Audio interface

Two-wire Global Coexistence Interface (GCI)

Integrated peripherals such as PWM, ADC

Programmable output power control
