Power MOSFET IRF3808STRRPBF IRF3808 N-Channel Surface Mount Type 75 V 106A

Power MOSFET IRF3808STRRPBF IRF3808 N-Channel Surface Mount Type 75 V 106A

Source:our siteTime:2022-11-11Views:

Mingjiada supplies Power MOSFET IRF3808STRRPBF IRF3808 N-channel surface mount type 75 V 106A, new and original, in stock, welcome to contact us if you are interested.

Mingjiada supplies Power MOSFET IRF3808STRRPBF IRF3808 N-channel surface mount type 75 V 106A, new and original, in stock, welcome to contact us if you are interested.


Model No: IRF3808STRRPBF

Batch number: 11+

Package: TO-263

Description: MOSFET N-CH 75V 106A D2PAK


Advantage

 Advanced process technology

 Ultra-low on-state resistance

 Dynamic dv/dt rating

 175°C operating temperature

 Fast switching

 Repeated avalanches allowed up to Tjmax

 Lead free


Property parameters

Product Type: MOSFET

Technology: Si

Mounting Style: SMD/SMT

Package / Case: TO-252-3

Transistor polarity: N-Channel

Number of Channels: 1 Channel

Vds - drain-source breakdown voltage: 75 V

Id-Continuous drain current: 106 A

Rds On - drain-source on-resistance: 7 mOhms

Vgs - Gate-source voltage: - 20 V, + 20 V

Vgs th - gate source threshold voltage: 4 V

Qg - gate charge: 150 nC

Minimum operating temperature: - 55 C

Maximum operating temperature: + 175 C

Pd - power dissipation: 200 W

Channel mode: Enhancement

Configuration: Single

Descent time: 120 ns

Forward transconductance - min: 100 S

Height: 2.3 mm

Length: 6.5 mm

Rise time: 140 ns

Typical close delay time: 68 ns

Typical turn-on delay time: 16 ns


Typical Applications

Industrial automotive
