Supply Power Management IC 338S0081C for iPhone 14pro max

Supply Power Management IC 338S0081C for iPhone 14pro max

Source:our siteTime:2022-10-22Views:

Supply Power Management IC 338S0081C for iPhone 14pro max

Supply Power Management IC 338S0081C for iPhone 14pro max



Apple's A16 chip uses the Qualcomm Snapdragon X65 baseband chip. Take a look at the iPhone 14 Pro Max disassembled and see what its core component suppliers and products are.


The chips corresponding to the different colours are shown below.

Red: SanDisk SDMVGKLK2 128G 128 GB NAND flash memory

Orange: Apple/Dialog Semiconductor 338S00819-A1 power management

Yellow: suspected Apple/Cirrus Logic 338S00843 voice processor

Green: Apple/Cirrus Logic 338S00537 Audio Amplifier

Light blue: suspected Apple/Dialog Semiconductor 338S0081C ? Power Management

Dark blue: Texas Instruments TPS61280H DC-DC converter

Purple: Probably STMicroelectronics EEPROM



The company also supplies the Apple 14pro max with the following part numbers

338S00819 Power management

338S00843 Voice processor

338S00537 Audio amplifier

338S0081C Power Management

TPS61280DYFFR DC-DC Converter

NTB0101GS1Z Voltage Level

LSF0101DRYR 1-bit Bidirectional Voltage Level Converter

APL109A/338S00942 Power Management Chips

338S00839-B0 Power Management Chip

BCM59365EA1IUBG Wireless Charging Receiver

STB601A05 Power Management Chip

338S00819-A1 Power Management Chip

TPS65657B0YCFR Display Power Supply

LM3567A1 LED Flash Driver

338S00738 Audio Codecs

CD3710A1YFDR VCSEL Array Driver

CBTL1618A0 Multiplexer

AFEM-8245 Front End Module

338S00537 Audio amplifier

PMX65 Power Management Chip

QET7100 Envelope Tracer

PM-K65 Clock Generator

SN210VUK/B101MU NFC Controller

AFEM-8231 Front End Module

SKY58290-20 Front-end Module

AFEM-8240 Front End Module

SKY58853-17 Front End Module

SKY52628 Antenna Switch Module

SKY5xx92-16 Power Amplification Module
