Transistor IRF3808STRLPBF MOSFET N-CH 75V 106A D2PAK

Transistor IRF3808STRLPBF MOSFET N-CH 75V 106A D2PAK

Source:our siteTime:2022-10-17Views:

Shenzhen Mingjiada Electronics supply transistor IRF3808STRLPBF MOSFET N-CH 75V 106A D2PAK, new and original, welcome to consult!

Shenzhen Mingjiada Electronics supply transistor IRF3808STRLPBF MOSFET N-CH 75V 106A D2PAK, new and original, welcome to consult!


Model: IRF3808STRLPBF

Batch number: 11+

Package: TO-263


Product Specification

FET Type N-channel

Technology MOSFET (metal oxide)

Current at 25°C - continuous drain (Id) 106A (Tc)

Drive voltage (max Rds On, min Rds On) 10V

On-resistance at different Id, Vgs (max) 7 milliohms @ 82A, 10V

Vgs(th) at different Id (max) 4V @ 250µA

Vgs (max) ±20V

FET function -

Power dissipation (max) 200W (Tc)

Operating Temperature -55°C ~ 175°C (TJ)

Mounting Type Surface Mount Type

Supplier Device Package D2PAK

Package/Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB

Drain source voltage (Vdss) 75 V

Gate charge (Qg) at different Vgs (max) 220 nC @ 10 V

Input capacitance (Ciss) at different Vds (max) 5310 pF @ 25 V
