Supply 100-000001377 AMD Ryzen 7 PRO 8840U Enterprise Class Processors

Supply 100-000001377 AMD Ryzen 7 PRO 8840U Enterprise Class Processors

Source:our siteTime:2024-09-04Views:

Shenzhen Mingjiada Electronics Co., Ltd. supply 100-000001377 AMD Rydragon 7 PRO 8840U enterprise-class processor.Basic informationProduct ID: 100-000001377 (FP7)Name: AMD Ryzen™ 7 PRO 8840UProduct Line: Ryzen PROSeries: Ryzen PRO 8000 SeriesForm fac…

Shenzhen Mingjiada Electronics Co., Ltd. supply 100-000001377 AMD Rydragon 7 PRO 8840U enterprise-class processor.


Basic information

Product ID: 100-000001377 (FP7)

Name: AMD Ryzen™ 7 PRO 8840U

Product Line: Ryzen PRO

Series: Ryzen PRO 8000 Series

Form factor: Desktop, 1L Desktops, laptop, Mobile Workstations

Original code name: Hawk Point

Architecture: Zen 4

CPU cores: 8

Multithreading (SMT) : Yes

Thread count: 16

Maximum acceleration clock rate: up to 5.1GHz

Benchmark clock frequency: 3.3 GHz

L2 cache: 8 MB

L3 cache: 16 MB

Default thermal design power (TDP) : 28W

AMD Configurable Thermal Design Power (cTDP) : 15-30W

CPU core processor process: TSMC 4nm FinFET

CPU Computing chip (CCD) Size: 178mm²

Package chip count: 1

CPU platform: FP7

Supported extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE2, SSE, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Maximum operating temperature (Tjmax) : 100°C


Features:

Advanced commercial computer processors help improve overall productivity. Up to eight high-performance cores built on the leading 4 nm process "Zen 4" architecture, coupled with Wi-Fi 7 support for ultra-fast Internet speeds, bring incredible productivity and responsiveness to business applications.

The integrated graphics card with AMD RDNA 3 architecture sets a new benchmark for visual performance, supports the latest high-resolution displays, and is optimized for high-fidelity video playback and video conferencing, while supporting AV1 playback.

Advanced, ultra-energy-efficient x86 processors help reduce energy consumption and minimize your carbon footprint.
