INFINEON Pressure Sensor SP4001101XTMA1 Automotive Tire Pressure Monitoring Sensor

INFINEON Pressure Sensor SP4001101XTMA1 Automotive Tire Pressure Monitoring Sensor

Source:our siteTime:2024-07-27Views:

INFINEON Pressure Sensor SP4001101XTMA1 Automotive Tire Pressure Monitoring SensorProduct DescriptionSP4001101XTMA1 is Automotive Tire Pressure Monitoring Sensor with pressure range 100 to 900 kPa.SP4001101XTMA1 provides a very high level of integrati…

INFINEON Pressure Sensor SP4001101XTMA1 Automotive Tire Pressure Monitoring Sensor


Product Description

SP4001101XTMA1 is Automotive Tire Pressure Monitoring Sensor with pressure range 100 to 900 kPa.

SP4001101XTMA1 provides a very high level of integration, and is optimized to perform all of the functions necessary to implement a state-of-the-art Tire Pressure Monitoring System (TPMS) sensor module.


Summary of Features

Patented Glass-Silicon-Glass MEMS pressure sensor with best-in-class media compatibility

Calibrated pressure sensor for absolute air pressure measurement

Z-axis accelerometer for motion detection and angular measurement

Temperature and supply voltage sensors

Industry-standard 8051 microcontroller with 12K of Flash memory

System Controller with flexible wake-up and power management features

RF Transmitter with fractional-N sigma-delta PLL

Unique firmware functions for determination of angular wheel position, supporting tire localization (APS)

LF Receiver allows carrier detection and modulated telegram reception


Potential Applications

Valve based TPMS-Modules

OEM

Aftermarket

Retrofit

In Tire TPMS Modules
