Renesas, a global semiconductor solutions provider, announced today the launch of the RAA489300/RAA489301 high-performance step-down controllers. This new controller adopts a three-level step-down topology and is specifically designed for battery charging and voltage regulation in USB-C systems. It is suitable for multi-port USB-PD chargers, portable power supplies, PC docking stations, robots, drones, and other applications that require high-efficiency DC/DC controllers.

The three-level step-down converter topology adopted by this new type of IC features outstanding efficiency and can significantly reduce the inductance required by the step-down converter. Its innovative design can minimize power loss and reduce system size to the greatest extent, making it an ideal choice for compact high-performance applications.

Compared with the traditional two-level step-down converter, the three-level topology adds two extra switches and a flyover capacitor. Flyover capacitors can reduce the voltage stress on the switch, enabling designers to use low-voltage FETs with a better quality factor, thereby effectively reducing conduction losses and switching losses. In addition, this topology also supports the use of smaller inductors, with the peak-to-peak ripple being approximately 25% of that of two-level converters, thereby reducing the core and DC resistance losses of the inductor.

Renesas' USB-PD solution features excellent quality and safety, while also offering high efficiency and power density. As a global provider of USB-PD solutions, Renesas offers a comprehensive product portfolio covering a wide range of applications, including turnkey solutions. With a wide range of development environments and pre-certified USB-IF reference designs, we help customers shorten the time to market for their products.

Gaurang Shah, Vice President of the Power Division at Renesas, said: "This three-level step-down topology solution is a prime example of Renesas' outstanding position in battery charging." This innovative technology incorporates multiple breakthrough patent achievements under review. Compared with the USB-C power supply solutions of competitors, it can bring obvious advantages to our customers.

The three-level DC-DC RAA489300/RAA489301 voltage regulator features outstanding thermal performance, which can reduce cooling requirements and thus save costs and space. This innovative approach meets the market's growing demand for compact and efficient power management systems.

Key features of RAA489300/RAA489301 voltage regulator:

It supports a wide range of input and output voltages and is suitable for battery packs of different voltages and various PD adapters

Integrated security functions; It is equipped with built-in overcharge, overheat and abnormal voltage protection mechanisms

Outstanding scalability enables easy adaptation to different power levels and application requirements

The optimized switch architecture distributes voltage between power switches, enhancing efficiency

Minimize power consumption to help achieve greener and more sustainable designs

Reduce thermal stress, enhance system reliability and extend product lifespan

Successful product portfolio

Renesas offers two successful product combinations, RTK-251-SinkChargers 240W and 240W dual-port sub-cards, which can minimize the development workload required for customers to integrate USB-C battery charging functions into their products. These "successful product portfolios" are based on mutually compatible and seamlessly collaborative products, featuring technically proven system architectures that offer optimized low-risk designs to accelerate time-to-market for products. Renesas has now launched over 400 "successful product portfolios" based on various products in its product lineup, enabling customers to accelerate the design process and bring their products to market more quickly. For more information, please visit renesas.com/win.

Supply information

The RAA489300/RAA489301 is now available in a 4mm × 4mm 32-pin TQFN package. It also offers comprehensive design support and tools, including the RTK-251-SinkCharge-240W kit and the RTKA489300DE0000BU evaluation board. For more information, please visit: https://www.renesas.com/raa489300.
