The TPS92543QPKDRQ1 automotive LED driver is an automotive-grade 65V synchronous boost controller featuring a 2A synchronous CC buck and bypass FET controller. The following are its core features:

• Complies with the AEC-Q100 standard for automotive applications

Class -1: Ambient operating temperature range of -40 °C to 125°C

-Device HBM classification grade H1C

- Device CDM classification grade C5

• Functional safety type

Documentation for the design of functional safety systems can be provided

A wide input voltage range from 4.5V to 65V

• Synchronous voltage reduction with integrated switches

The continuous output current is up to 2A with an accuracy of 4%

• Synchronous boost controller

- Programmable output voltage up to 65V

Six dangling gate drivers for shunting FET dimming

- Programmable width and phase Settings

-Programmable PWM frequency

• Boost and step-down spread spectrum for reducing EMI

• Overheat protection of the voltage reduction switch

• UART serial communication

- An internal oscillator for the system clock

-LMM compatible

• Internal EEPROM

- Default Settings

- Customer calibration data

For details

The TPS92543QPKDRQ1 device incorporates a synchronous boost controller and a single-chip synchronous buck LED driver, featuring a wide buck input operating voltage range from 4.5V to 65V. The TPS92543QPKDRQ1 consists of two sub-light strings of three series-connected floating bypass FET controllers.

The synchronous boost controller implements a peak current mode controller that can operate in constant voltage mode. The boost converter has been programmed to operate in two phases together with another TPS92543. The output voltage can be programmed using a programmable 8-bit DAC.

The single-chip synchronous step-down driver can achieve adaptive on-time average current mode control function and is designed to be compatible with shunt FET dimming technology and dynamic beam headlamps based on LED matrix managers. The adaptive on-time control function can provide a nearly constant switching frequency, with a frequency setting range of 100kHz to 1.0MHz. The inductor current detection and closed-loop feedback function can achieve an accuracy better than ±4% over a wide range of input voltage, output voltage and ambient temperature.

The TPS92543QPKDRQ1 features two sub-strings of three series-connected floating bypass FET controllers, capable of performing LED parallel FET dimming. Each controller can perform FET dimming, with a segment voltage as high as 55V. The device includes programmable registers for each individual phase shift and pulse width.

The TPS92543QPKDRQ1 includes an internal oscillator. The UART serial interface is compatible with TPS9266x and TPS9254x devices. The internal EEPROM can store system default values as well as calibration and lighting module data. Four configurable MPIOs can be configured as digital inputs or outputs, or ADC inputs, for system temperature compensation, LED grading and encoding.

The TPS92543QPKDRQ1 is available in a 7.0mm × 7.0mm heat-enhanced 48-pin HTQFP package with exposed pads.

Typical applications

• Automotive headlamps and adaptive LED driver modules

Performance parameters

Product: TPS92543QPKDRQ1

Type: DC-DC controller, DC-DC voltage regulator

Topology: Step-down, step-up

Internal switch: Yes

Output number: 6

Voltage - Power supply (minimum) : 4.5V

Voltage - Power supply (maximum) : 65V

Voltage - Output: 65V

Current - Output/Channel: 2A

Frequency: 100 KHZ to 1MHz

Dimming: Yes

Application: General

Operating temperature: -40°C to 125°C (TA)

Grade: Automotive grade

Qualification: AEC-Q100

Installation type: Surface mount type

Package: 48-HTQFP (7x7)

Supply information

For the TPS92543QPKDRQ1 automotive LED driver, please visit www.hkmjd.com.
