Mingjiada Electronics specialises in supplying genuine TLE42754G automotive-grade LDO voltage regulators. This product is housed in a 5-pin TO-263-5 package and is a monolithic integrated low-dropout voltage regulator specifically designed for automotive electronics. It can stabilise and regulate an input voltage of up to 42V to an output voltage of 5.0V, with a maximum output current of 450mA.

The TLE42754G integrates multiple protection features, including over-temperature shutdown, short-circuit protection, and reverse polarity protection, and allows the power-on reset delay time to be set via an external delay capacitor. Its operating temperature range spans -40°C to +150°C, fully compliant with the AEC-Q100 automotive electronics certification standard.

TLE42754G Product Features

Designed specifically for automotive applications: Complies with AEC-Q100 standards, ensuring high reliability and stability in automotive environments.

Low-dropout (LDO) design: Maintains stable output voltage even at low input voltages, suitable for automotive start-up and idle conditions.

High output current: Maximum output current up to 2A, meeting various load requirements.

Low quiescent current: Quiescent current as low as 1.5mA, helping to extend battery life.

Wide Input Voltage Range: Input voltage range from 4.5V to 36V, suitable for fluctuations in automotive battery voltage.

Multiple Protection Features: Built-in overcurrent protection, short-circuit protection, and over-temperature protection ensure safe operation.

Compact Packaging: 5-pin TO package, suitable for compact automotive electronic system designs.

TLE42754G Technical Specifications

Input voltage range: 4.5V to 36V

Output voltage: 5V (fixed)

Maximum output current: 2A

Quiescent current: 1.5mA (typical)

Low dropout voltage: 150mV (typical)

Operating temperature range: -40°C to +150°C

Package type: 5-pin TO package

TLE42754G Application Scenarios

Automotive Electronics Systems: Suitable for automotive electronic control units (ECUs), in-vehicle chargers, infotainment systems, etc.

Industrial Applications: Provides stable power management in industrial automation equipment.

Consumer Electronics: Used in power management modules requiring high reliability and low power consumption.

Functional Block Diagram

Mingjiada Electronics' Inventory Availability Advantages

Inventory Availability: Ample stock, fast delivery, meeting urgent project needs.

Quality Assurance: Strictly controlling product quality to ensure each chip meets original manufacturer standards.

One-Stop Service: Offering a variety of electronic components to meet customers' one-stop procurement needs.
