Automotive Connector_MINI-MSDF000F_MINI MSD Socket, Front Mounting

Automotive Connector_MINI-MSDF000F_MINI MSD Socket, Front Mounting

Source:our siteTime:2025-07-16Views:

Shenzhen Mingjiada Electronics Co., Ltd. supplies genuine, in-stock Amphenol automotive connectors_MINI-MSDF000F_MINI MSD socket, front-mounted installation, high-voltage maintenance disconnect ‘safety switch’Amphenol MINI-MSDF000F Automotive Connec…

Shenzhen Mingjiada Electronics Co., Ltd. supplies genuine, in-stock Amphenol automotive connectors_MINI-MSDF000F_MINI MSD socket, front-mounted installation, high-voltage maintenance disconnect ‘safety switch’


Amphenol MINI-MSDF000F Automotive Connector Product Introduction

Product Overview

The MINI-MSDF000F is a high-voltage connector socket from Amphenol's MINI MSD series, featuring a front-mounted design specifically developed for high-voltage systems in new energy vehicles. As a key component of the Manual Service Disconnect (MSD) system, this product serves a safety protection function in the high-voltage battery systems of electric vehicles and hybrid vehicles.


Core Features

Front-mounted design: Facilitates installation and operation in confined spaces

High-voltage safety protection: Integrated high-voltage interlock (HVIL) functionality

Compact structure: Small footprint, saving installation space

High reliability: Meets automotive-grade environmental requirements

Quick disconnect: Enables rapid disconnection of high-voltage circuits in emergency situations


Technical Specifications

Product Type:    Automotive Connectors

Product:    Connectors

Type:    Receptacle (Female)

Mounting Style:    Mounting Flange

Termination Type:    Screw

Series:    Mini MISD

Description/Function:    IP67, IP6K9K Protection Degree

Entry Protection:    IP67, IP6K9K

Maximum Operating Temperature:    +70°C

Minimum Operating Temperature:    -40°C

Voltage Rating:    1.5 kV


Application Areas

Battery Electric Vehicles (BEV) High-Voltage Battery Systems

Plug-in Hybrid Electric Vehicles (PHEV) Powertrain Systems

Commercial Vehicle High-Voltage Distribution Units

Energy Storage System Safety Disconnect Devices


Mingjiada Electronics Supply Advantages

Shenzhen Mingjiada Electronics Co., Ltd. maintains a long-term stock of MINI-MSDF000F connectors, ensuring genuine products, and provides the following services:

Professional selection support

Quick delivery from stock

Volume purchase discounts

Technical support services


Contact Information

Contact Person: Mr. Chen

Phone: +86 13410018555

Email: sales@hkmjd.com

Website: www.hkmjd.com

Address: Room 1239-1241, Xinyazhou Guoli Building, Zhenzhong Road, Futian District, Shenzhen City
