The ADA4077-2ARMZ is a dual-channel precision amplifier launched by (ADI), featuring the following core characteristics:

Offset voltage: 50 μV

Offset voltage drift: 0.55 μV/℃

Rated MSL1

Low input bias current: 1 nA (maximum value, TA = 25°C)

Low-voltage noise density: 6.9 nV/√Hz (typical value, f = 1000 Hz)

CMRR, PSRR and AV > 120 dB (minimum value)

Low supply current: 400 μA per amplifier (typical value)

Wide gain bandwidth product: 3.9 MHz (±5 V)

Dual power supply

The rated value is ± 5V to ± 15V

The working voltage ranges from ± 2.5V to ± 15V

Unit gain stability

No inverse phase

Long-term offset voltage drift (10,000 hours) : 0.5 μV (typical value)

Temperature hysteresis: 1 μV (typical value)

Introduction

The ADA4077-2ARMZ is a basket of dual-channel operational amplifiers, featuring extremely low offset voltage and drift, as well as low input bias current, noise and power consumption. When using capacitive loads of 1000 pF or more, the output is stable and no external compensation is required.

The applications of the ADA4077-2ARMZ amplifier include sensor signal conditioning (such as thermocouples, resistance temperature detectors (RTDS), strain gauges), process control front-end amplifiers, and precise diode power measurement in optical and wireless transmission systems. The ADA4077-2ARMZ is also suitable for portable instruments and meters powered by lines, precision filters, and voltage or current measurement and level setting.

Unlike other amplifiers, the ADA4077-2ARMZ features MSL1 rated performance, complies with strict assembly process standards, and has a rated temperature range of -40 °C to +125°C, extending the industrial temperature range and making it suitable for demanding working environments.

Key parameters

Product: ADA4077-2ARMZ

Amplifier type: Standard

Number of circuits: 2

Output type: -

Slew rate: 1.2V/µs

Gain-bandwidth product: 3.6 MHz

-3 dB bandwidth: 5.5 MHz

Current - Input bias: 400 pA

Voltage - Input compensation: 50 µV

Current - Power supply: 400µA (x2 channels)

Current - Output/Channel: 10 mA

Voltage - span (minimum value) : 5 V

Voltage - span (maximum value) : 30 V

Operating temperature: -40°C to 125°C

Installation type: Surface mount type

Packaging/Housing: 8-MSOP

Application field

The ADA4077-2ARMZ amplifier is suitable for the following application fields:

Process control front-end amplifier

Optical fiber network control circuit

Instruments and meters

Precision sensors and control components

Precision filter
