Motorcomm YT8522 Product Description

The YT8522 is a low power single port 10/100 Mbps Ethernet PHY.

The YT8522 provides all the physical layer functionality required to send and receive data over a standard twisted pair transceiver or fibre optic PECL interface to an external 100Base-FX optical transceiver module. In addition, the YT8522 provides flexible connectivity to MACs via standard MII and RMII interfaces.

The YT8522 employs mixed-signal processing for equalisation, data recovery and error correction for robust operation over CAT5 twisted pair or 100Base-FX optical transceiver modules.

Key Features

Supports IEEE 802.3az (Energy Efficient Ethernet)

100Base-TX IEEE 802.3u Compliant

10Base-Te IEEE 802.3 Compliant

Supports MII mode

Supports RMII mode

Supports I/O 1.5V/1.8V/2.5V/3.3V (except for Crystal)

Full/Half duplex operation

100BASE-FX support (share with MDI pins)

Twisted pair or fiber mode output

Supports Auto-negotiation

Supports Power down mode

Supports Base Line Wander (BLW) compensation

Supports Auto MDIX

Supports Interrupt function

Supports WOL, Wake on Lan

Automatic Polarity correction

2 sets LED indicator

25MHz crystal or external OSC

50MHz external OSC input

Provide 50Mhz clock source for MAC

Single Power supply, internal LDO

Package QFN 32, 5x5mm

Target Applications

Ethernet Switch

DTV (Digital TV)

Communication and Network Riser

Routers, PON Equipment

Printer and Office Machine

MAU(Media Access Unit)
