Mingjiada Electronics Supply Driver Infineon 1EDC60H12AH 1200 V High Side Single Channel Gate Driver IC with UL approved galvanic isolation, short circuit clamping and independent sink/pull current output pins.

Shenzhen Mingjiada Electronics Co., Ltd, as a leading electronic components supply chain service provider, specialises in supplying Infineon genuine 1EDC60H12AH 1200V high-side single-channel gate driver ICs.1EDC60H12AH adopts the innovative coreless transformer technology with excellent isolation performance and driving capability, widely used in power electronics, industrial control and new energy fields, industrial control and new energy etc.

Product Description: 1EDC60H12AH

The 1EDC60H12AH is a high performance gate driver IC from Infineon's EiceDRIVER™ family in the PG-DSO-8-59 package. 1EDC60H12AH is designed to drive 600V/650V/1200V IGBTs, MOSFETs, and SiC MOSFETs, and provides up to 10A output current at separated output pins. output current at separate output pins.

With scaled CMOS threshold levels on the input logic pins, the 1EDC60H12AH supports a wide input voltage range of 3V to 15V for compatibility with 3.3V microcontroller systems.1The 1EDC60H12AH achieves data transfer across the isolation barrier via coreless transformer technology, and each driver is equipped with a logic input and driver output undervoltage lockout (UVLO) and an active shutdown functions.

Specification

Model No.: 1EDC60H12AH

Package: PG-DSO-8

Output Current (Source) Typical: 10.0A

Output Current (Drain) Typical: 9.4A

Operating Voltage Range: 3.1V~17V

Isolation Voltage: VISO=3000V (UL1577 certified)

Rise time (max): 10ns

Down time (max): 9ns

Operating temperature range: -40°C~+125°C

Switching frequency (max): 1000kHz

Creepage distance: 8mm

The 1EDC60H12AH is available in a 300 mil wide body package with 8mm creepage distance to ensure safety and reliability in high voltage applications. 1EDC60H12AH has an input VCC of 3.1V minimum and 17V maximum, providing full flexibility in system design.

Product Features

High-performance drive capability: Provides rail-to-rail outputs with typical peak currents up to 10A for fast switching of high-power devices.

Excellent isolation performance: UL1577 certified with insulation test voltage up to 3000V for 1 second to ensure system safety.

Wide Operating Voltage Range: Supports a wide input voltage range of 3V to 15V, compatible with a wide range of control systems.

Independent source-sink outputs: with separate source and sink outputs for more flexible gate drive design.

High-temperature capability: Suitable for operation in high ambient temperatures to meet the demands of harsh industrial environments.

Fast switching characteristics: with fast propagation delays of 120ns typical and 142ns maximum.

Compact package: PG-DSO-8 package to save PCB space.

Product Applications

1EDC60H12AH is widely used in the following applications:

AC and brushless DC motor drives

High voltage DC/DC converters and DC/AC inverters

Induction heating resonant applications

UPS systems, welding and solar energy

The 1EDC60H12AH supplied by Mingjiada Electronics are genuine Infineon products, with reliable quality and sufficient stock. 1EDC60H12AH has become the preferred driver IC in power electronic system design due to its excellent performance and reliability. 1EDC60H12AH's wide operating voltage range and high drive capability make it adaptable to a variety of complex application environments. The compact package design of the 1EDC60H12AH also provides an ideal solution for space-constrained applications.
