[Supply] IRS2186STRPBF (Infineon) 600V, EiceDRIVER™ High-Side And Low-Side Gate Driver IC

Shenzhen Mingjiada Electronics Co., Ltd.——Long-term supply of Infineon's (IRS2186STRPBF) EiceDRIVER™ 600V high-side and low-side gate driver ICs with typical 4A pull and 4A sink currents in 8-pin SOIC packages for IGBTs and MOSFETs.

Product Details:

The IRS2186STRPBFs are high-voltage, high-speed power MOSFET and IGBT drivers with independent high-side and low-side reference output channels. The floating channel can be used to drive N-channel power MOSFETs or IGBTs in a high voltage side configuration with operating voltages up to 600V.

Part Number: IRS2186STRPBF

Package: SOIC-8

Type: High Side and Low Side Gate Driver ICs

Product Diagram:

The IRS2186STRPBF features proprietary HVIC and latch-immune CMOS technology for a rugged monolithic structure. The logic inputs are compatible with standard CMOS or LSTTL outputs with logic voltages as low as 3.3 V. The output drivers feature a high pulse current buffer stage designed to minimise driver cross-conduction.

IRS2186STRPBF Specifications:

Driver Configuration: High Voltage Side or Low Voltage Side

Channel Type: Standalone

Number of drivers: 2

Gate Type: IGBT, MOSFET (N-Channel)

Voltage - Supply: 10V ~ 20V

Logic Voltage - VIL, VIH: 0.8V, 2.5V

Current - Peak Output (Pour In, Pull Out): 4A, 4A

Input Type: Non-Inverting

High Side Voltage - Maximum (Bootstrap): 600 V

Rise/Fall Time (typical): 22ns, 18ns

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Surface Mount

Package/Shell: 8-SOIC (0.154’, 3.90mm Width)

Supplier Device Package: 8-SOIC

IRS2186STRPBF Application Areas:

Industrial automation

Household appliances

Light Electric Vehicles

Power transmission and distribution

Vacuum Cleaners

IRS2186STRPBF - Functional Block Diagram:

[Mingjiada Electronics] Long-term supply of Infineon (IRS2186STRPBF) 600V EiceDRIVER™ high and low side gate driver ICs, for more information about IRS2186STRPBF products, welcome to visit the official website of Mingjiada Electronics (www.hkmjd.com).
