As a professional electronic components supplier, Mingjiada Electronics has been supplying Infineon SAK-TC234L-32F200F AB and its series of microcontrollers for a long time. The SAK-TC234L-32F200F AB is designed for automotive electronics and industrial automation applications and features a 200MHz high-performance TriCore™ CPU, 2MB Flash memory and ASIL-D Safety certified for critical systems such as Electric Power Steering (EPS), Body Control Modules (BCM) and more. Mingjiada Electronics provides genuine products, in-stock inventory and professional technical support to help customers accelerate product development and mass production.

SAK-TC234L-32F200F AB Product Overview

The SAK-TC234L-32F200F AB is a high-performance microcontroller from Infineon, belonging to the AURIX™ TC23xL family, featuring an innovative multicore architecture based on up to three independent 32-bit TriCore CPUs, designed to meet extremely high safety standards while offering a significant increase in performance.

SAK-TC234L-32F200F AB Product Features

Core and Processing Power: 32-bit TriCore™ CPUs, capable of processing speeds up to 200MHz, and DSP functionality, enable fast processing of complex computational tasks for applications requiring high real-time performance.

Storage capacity: 2MB of flash memory with ECC protection to ensure the reliability and integrity of data storage. Meanwhile, it is equipped with 192KB SRAM and 128KB EEPROM, which provides sufficient space for programme operation and data storage.

Interfaces and Functions: Rich interfaces and functions, including 4 SENT sensor interfaces, 1 FlexRay interface, 2 ASCLIN interfaces, 4 QSPI interfaces, 6 CAN/CAN FD nodes, etc., which can satisfy a wide range of communication and data transmission needs.

Safety features: Compliant with ISO 26262 ASIL-D and IEC 61508 SIL3 safety standards, the device is equipped with a variety of safety features such as clock-delayed lock-step cores, redundant and diversified timer modules, an access authorisation system, and a safety management unit, which make it suitable for applications with high safety requirements.

Operating conditions: With an operating voltage of 3.3V, the SAK-TC234L-3 is able to operate stably over an ambient temperature range of - 40°C to + 125°C, making it suitable for a wide range of harsh operating conditions.

SAK-TC234L-32F200F AB Product Attributes

Product Category: 32-bit Microcontrollers - MCUs

Mounting Style: SMD/SMT

Package / Case: TQFP-144

Core: TriCore

Programme memory size: 2 MB

Data RAM size: 704 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 200 MHz

Supply voltage - min: 1.17 V

Supply voltage - max: 1.43 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Fields of application

SAK-TC234L-32F200F AB microcontrollers are used in a wide range of automotive and industrial applications, such as wireless charging solutions, advanced gateway architectures, remote control units and V2X, and highly functional body area control units, thanks to their excellent performance and rich functionality.

All SAK-TC234L-32F200F AB supplied by Mingjiada Electronics are original and genuine, which ensure the reliable quality of products and customers can purchase with confidence.
