Mingjiada Electronics specialises in supplying Texas Instruments (TI) original genuine TMS320F28335PGFA high-performance 32-bit real-time microcontroller. The device is the flagship product in the TI C2000™ family, integrating a floating-point unit (FPU), 512KB Flash memory and a rich peripheral interface, designed for industrial automation, motor control and digital power and other real-time control applications.

TMS320F28335PGFA Product Description

The TMS320F28335PGFA is a high-performance 32-bit real-time microcontroller from Texas Instruments (TI), part of the C2000™ family. The product is designed for industrial control, digital power, motor control and other applications, with excellent real-time processing capabilities and rich peripheral resources.

TMS320F28335PGFA Product Features

High-performance processor: 32-bit TMS320C28x CPU with up to 150MHz main frequency, supporting single-cycle multiplication and hardware floating-point operations.

Storage capacity: 512KB Flash memory and 68KB SARAM to meet the needs of complex programme storage.

ADC module: 12-bit 16-channel ADC with 80ns conversion speed.

PWM output: 18-channel high-precision PWM with a resolution of 150ps.

Communication interfaces: Supports various communication interfaces such as CAN, SCI, SPI, I2C and McBSP.

Peripheral resources: including enhanced PWM (ePWM), high-precision capture unit (eCAP), quadrature encoder interface (QEP) and so on.

Development tools: Provides development tools and software libraries such as Code Composer Studio (CCS) and ControlSUITE.

TMS320F28335PGFA Product Parameters

Electrical parameters:

CPU main frequency: 150MHz

Operating voltage: 1.8V core, 3.3VI/O

Flash memory: 512KB

SARAM: 68KB

ADC: 12-bit, 16 channels

PWM: 18 channels, 150ps resolution

Physical Parameters:

Package: 176-pin LQFP (PGF)

Dimensions: 24mm x 24mm

Environmental parameters:

Operating temperature range: -40°C to +85°C

TMS320F28335PGFApplication areas

Industrial automation: for motor control, digital power conversion, photovoltaic inverters, etc.

Electric vehicles: for battery management systems, on-board chargers, etc.

Consumer electronics: for home appliances, power tools, etc.

New energy: photovoltaic inverters, energy storage systems, etc.

Advantages of Mingjiada Electronics

Spot supply: Mingjiada has sufficient stock of TMS320F28335PGFA, and can respond to customer needs quickly.

Quality assurance: all products are original and genuine, after strict quality testing.

Technical Support: Provide professional technical support to help customers better apply the product.

If you are interested in TI C2000™ MCU TMS320F28335PGFA, please feel free to contact Mingjiada Electronics. We will provide you with detailed product information, quotation and technical support.
