FPGA LCMXO2-2000HC-4BG256C IC FPGA 206 I/O 256CABGA

FPGA LCMXO2-2000HC-4BG256C IC FPGA 206 I/O 256CABGA

Source:our siteTime:2022-07-27Views:

Mingjiada Supply Original FPGA LCMXO2-2000HC-4BG256C IC FPGA 206 I O 256CABGA

Mingjiada Supply Original FPGA LCMXO2-2000HC-4BG256C IC FPGA 206 I O 256CABGA


MachXO2 Family Product Description: The MachXO2 Programmable Logic Device (PLD) consists of six ultra-low-power, instant-on, non-volatile PLDs that offer densities from 256 to 6864 look-up tables (LUTs). In addition, Lattice Semiconductor's MachXO2 family of PLDs offer features such as Embedded Block RAM (EBR), Distributed RAM, and User Flash Memory (UFM) that enable these devices to be used in low-cost, high-volume consumer users and applications in the system.


MachXO2 devices are designed on a 65nm non-volatile low power process and are available in two versions - ultra low power (ZE) and high performance (HC and HE). A variety of advanced halogen-free packages are also available and offer enhanced I/O features such as drive strength control, slew rate control, PCI compatibility, bus keeper latches and pull-up resistors. MachXO2 also provides flexible, reliable and secure configuration via on-chip flash memory.


Product Category: FPGA - Field Programmable Gate Array

Series: LCMXO2

Number of logic elements: 2112 LE

Number of inputs/outputs: 206 I/O

Operating supply voltage: 2.5 V/3.3 V

Minimum operating temperature: 0 C

Maximum operating temperature: + 85 C

Installation style: SMD/SMT

Package/Case: CABGA-256

Distributed RAM: 16 kbit

Embedded Block RAM - EBR: 74 kbit

Maximum operating frequency: 269 MHz

Moisture Sensitivity: Yes

Number of Logical Array Blocks - LAB: 264 LAB

Operating supply current: 4.8 mA

Product Type: FPGA - Field Programmable Gate Array

Factory Pack Quantity: 119

Subcategory: Programmable Logic ICs

Total memory: 170 kbit
