ADE7913ARIZ ADE7913 Isolated 3-Channel Sigma-Delta ADC Data Acquisition - Dedicated

ADE7913ARIZ ADE7913 Isolated 3-Channel Sigma-Delta ADC Data Acquisition - Dedicated

Source:our siteTime:2022-06-18Views:

​Mingjiada sells and recycles ADE7913ARIZ ADE7913 isolated 3-channel Σ-Δ ADC data acquisition - special type, imported original, factory stock in stock, welcome to contact!

Mingjiada sells and recycles ADE7913ARIZ ADE7913 isolated 3-channel Σ-Δ ADC data acquisition - special type, imported original, factory stock in stock, welcome to contact!


Model: ADE7913ARIZ

Brand: AD

Lot number: 21+

Package: SOP


Feature

Two (ADE7912) or three (ADE7913) 24-bit isolated, sigma-delta

Analog-to-digital converter (simultaneous sampling ADC)

Integrated isoPower, isolated DC-DC converter

On-chip temperature sensor

4-wire SPI serial interface

Up to four ADE7912/ADE7913 devices are clocked from a single

Crystal or external clock

Synchronization of Multiple ADE7912/ADE7913 Devices

±31.25 mV peak input range for current channel

±500 mV peak input range for voltage channels

Reference Drift: 10 ppm/°C (typ.)

Single 3.3 V supply

20-Pin Wide Body SOIC Package with 8.3 mm Creepage

Operating temperature: −40°C to +85°C

Safety and Regulatory Approvals (pending)

UL recognized

5000 V rms for 1 minute per UL 1577

CSA Component Acceptance Notice #5A

IEC 61010-1: 400 volts rms

VDE certificate of conformity

DIN VDE V 0884-10 (VDE V 0884-10):2006-12

V IORM = 846 V peak


Application

Shunt-Based Multiphase Instrumentation

Power Quality Monitoring

Solar inverters

Process Monitoring

protective device

Isolated sensor interface

Industrial PLC
