(Recycling, supply) [Switching regulator] LMR36006BQRNXRQ1 TI Automotive 4.2V to 60V, 0.6A ultra-small synchronous step-down converter, if necessary, welcome to call us.

Product Details:

The LMR36006BQRNXRQ1 regulator is an easy to use synchronous buck DC/DC converter. The device features integrated high - and low-side power MOSFETs capable of delivering up to 0.6A output current (over a wide input voltage range of 4.2V to 60V). Tolerance up to 66V.

The LMR36006-Q1 uses a peak current mode control mechanism to provide optimal efficiency and output voltage accuracy. The LMR36006-Q1 uses an advanced high-speed circuit to achieve voltage regulation from 20V input to 5V output at a fixed frequency of 2.1MHz. Precision enablement provides flexibility by enabling direct connection to a wide input voltage or precise control of device startup and shutdown. A power supply health marker with built-in filtering and delay provides a true indication of system status, eliminating the need for external monitors.

The LMR36006-Q1 is packaged in HotRod™ for low EMI, higher efficiency and an ultra-small package to chip ratio. This device requires few external components and has a pin arrangement that simplifies PCB layout. The small solution size and various features of the LMR36006-Q1 are designed to simplify the implementation of various end devices.

LMR36006BQRNXRQ1 Technical parameters:

Function: Depressurize

Output configuration: positive

Topology: depressurize

Output type: Adjustable

Output number: 1

Voltage - input (min) : 4.2V

Voltage - input (Max) : 60V

Voltage - output (min/fixed) : 1V

Voltage - output (Max) : 57V

Current - Output: 600mA

Frequency - Switch: 1MHz

Synchronous rectifier: Yes

Operating temperature: -40°C ~ 150°C (TJ)

Mounting type: Surface mount, wets flanks

Package/case: 12-VFQFN

Supplier Package: 12-VQFN-HR (3x2)

Applications:

• ADAS camera module

• Body control module
