【Distributed TI】Amplifier IC OPA2313ID General Purpose Amplifier 2 Circuit Full Swing 8-SOIC

【Distributed TI】Amplifier IC OPA2313ID General Purpose Amplifier 2 Circuit Full Swing 8-SOIC

Source:our siteTime:2023-08-21Views:

Shenzhen Mingjiada Electronics Co., Ltd. imported original [distribution TI] amplifier IC OPA2313ID dual, 5.5V, 1MHz, low quiescent current (50μA), RRIO operational amplifierProduct Overview:The OPA2313ID dual operational amplifiers represent a new g…

Shenzhen Mingjiada Electronics Co., Ltd. imported original [distribution TI] amplifier IC OPA2313ID dual, 5.5V, 1MHz, low quiescent current (50μA), RRIO operational amplifier


Product Overview:

The OPA2313ID dual operational amplifiers represent a new generation of low-cost, general-purpose, micropower operational amplifiers. The combination of rail-to-rail input and output swing, low quiescent current (50μA typical) with a wide 1MHz bandwidth and very low noise (25nV/√Hz at 1kHz) makes this family attractive for a wide range of battery-powered applications requiring a good balance between cost and performance. The low input bias current supports op amps used in applications with megohm source impedances.


The OPA2313ID device's robust design makes it easy for circuit designers to use: gain-per-unit stability with load capacitances up to 150pF, an integrated RF/EMI suppression filter, no phase reversal in the event of overdrive, and high electrostatic discharge (ESD) protection (4kV human body model (HBM)).


The device is optimised for low-voltage operation down to +1.8V (±0.9V) and up to +5.5V (±2.75V), and is rated for operation over the full extended temperature range of -40°C to +125°C at 1.8V, 3.3V and 5V.


Features:

Low IQ: 50µA/ch

Wide supply voltage: 1.8V to 5.5V

Low noise: 25nV/√Hz at 1kHz

Gain bandwidth: 1MHz

Low input bias current: 0.2pA

Low offset voltage: 0.5mV

Unit gain stabilisation

Internal Radio Frequency (RF) / Electromagnetic Interference (EMI) Filters

Extended temperature range: -40°C to +125°C


If you are interested, please feel free to contact Mr Chen by phone:

Tel: +86 13410018555,

Email: sales@hkmjd.com

Company website: www.hkmjd.com
