Overview

Product Description

The ADUCM322BBCZI is a fully integrated, single-package device with integrated high-performance analogue peripherals and digital peripherals controlled by an 80 MHz ARM® Cortex™-M3 processor and integrated Flash memory for code and data.

The ADUCM322BBCZI's built-in ADC is capable of 12-bit, 1 MSPS data acquisition over up to 16 input pins. In addition, chip temperature and supply voltage can be measured.

The ADC input voltage range is from 0 V to VREF, and a sequencer allows the user to select a group of ADC channels to be measured sequentially without software intervention. The sequence can be selected to repeat automatically at a user-selected rate. Up to 8 VDACs are provided and the output range can be programmed to one of two voltage ranges.

It can be configured so that its digital and analogue outputs retain their output voltages through a watchdog or software reset sequence. As a result, the product continues to operate even if it is being reset.

The ADUCM322BBCZI features a low-power ARM Cortex-M3 processor and a 32-bit RISC machine with peak performance up to 100 MIPS. two 128 kB Flash/EE memory modules and 32 kB SRAM are also integrated on-chip. the Flash memory consists of two independent 128 kB modules, which allows one Flash module to execute the program while the other Flash module writes/writes. Flash memory consists of two independent 128 kB modules, allowing one Flash module to execute programs while the other performs write/erase operations.

Advantages and features

Analogue Input/Output

Multi-channel, 12-bit, 1 MSPS analogue-to-digital converter (ADC)

Up to 16 ADC input channels

Analogue input range: 0 V to VREF

Single-ended mode

AVDD and IOVDD monitors

12-bit voltage output digital-to-analogue converter (VDAC)

8 VDACs providing 0 V to 2.5 V or AVDD outputs

Voltage Comparator

Microcontroller

ARM Cortex-M3 processor, 32-bit RISC architecture

Serial line port to support code download and debugging

Clock Options

80 MHz phase-locked loop (PLL) with programmable divider

On-chip tuned oscillator (±3%)

External 16 MHz crystal option

External clock source up to 80 MHz

Memory

Two 128 kB independent Flash/EE memories

Flash/EE endurance: 10,000 cycles

Flash/EE retention time: 20 years

32 kB SRAM

Software-triggered in-circuit reprogramming capability via management data input/output (MDIO)

On-chip peripherals

MDIO slave up to 4 MHz

2 × I2C, 2 SPI, UART

Multiple general purpose input/output (GPIO) pins: 3.6 V compatible

7 × 1.2 V compatible (when used for MDIO)

32-cell programmable logic array (PLA)

3 general-purpose timers

Wake-up timer

Watchdog timer

16-bit Pulse Width Modulator (PWM)

Power supply

Voltage range: 2.9 V to 3.6 V

Flexible operating modes for low-power applications

Package and temperature range

6 mm × 6 mm, 96-pin CSP_BGA package

Rated operating temperature range: -40°C to +105°C

Tools

QuickStart development system

Full third-party support

Applications

Fibre optic network
