(Supplied, recycled) ARM Cortex-M33 core LPC5506JHI48QL Microcontroller (NXP) 96MHz 256KB FLASH 48-HVQFN.

Product Details:

The LPC5506JHI48QL MCU has advanced security, making it ideal for industrial, iot, and general embedded applications. The LPC5506 Arm Cortex-M33 based microcontroller features a CASPER encryption engine with up to 256KB of on-chip flash memory and up to 96KB of on-chip SRAM. The MCU also includes a PRINCE module for dynamic flash encryption/decryption. The LPC550x includes a number of timers, including Code Watchdog, CAN FD, five universal timers, a Sctimer/PWM, an RTC/ alarm timer, a 24-bit multi-rate timer (MRT), and a Window Watchdog Timer (WWDT). In addition, a number of flexible serial communication peripherals, a programmable logic unit (PLU) and a 16-bit 2.0M sample/second ADC capable of simultaneous conversion, comparator and temperature sensor are included.

The device provides a secure foundation for isolation, protecting valuable IP and data through Trustzone® technology. The LPC5506 simplifies the design and software development of digital signal control systems by integrating digital signal processing (DSP) instructions.

The LPC5506 MCU meets security requirements for secure startup, HASH, AES, RSA, UUID, dynamic encryption and decryption, debug authentication, and TBSA compliance.

LPC5506JHI48QL Technical Specifications:

Core processor: ARM® Cortex®-M33

Kernel specification: 32-bit single-core

Speed: 96MHz

Connection capability: CANBus, Flexcomm, I²C, SPI, UART/USART

Peripheral: Undervoltage detection/reset, DMA, I²S, POR, PWM, RNG, WDT

Number of I/ OS: 30

Program storage capacity: 256KB (256K x 8)

Program memory type: Flash

EEPROM capacity: -

RAM size: 96K x 8

Voltage - power supply (Vcc/Vdd) : 1.8V ~ 3.6V

Data converter: A/D 7x16b SAR

Oscillator type: Internal

Operating temperature: -40°C ~ 105°C (TA)

Mounting type: Surface mount, wets flanks

Package/housing: 48-VFQFN bare pad

Supplier Package: 48-HVQFN (7x7)

Basic product number: LPC5506

Applications:

• Industrial and building automation

- Remote IO and sensor nodes

- Elevators and lifts

- Smart lighting and utility tools

• Consumer electronics

- Games and PC peripherals

- Vehicle/asset tracking system

- Silent power tools and appliances

• Smart home

- Security/biometric access control

- Security system

- Sensor node
