Mingjiada Corporation Supplies, Acquires TI 32-bit MCU TMS320F28335ZAYA C2000™ 32-bit Microcontrollers with 150MIPS, FPU, 512KB Flash, EMIF, 12-bit ADCs

Description

The TMS320F28335ZAYA C2000™ real-time microcontrollers are optimised for processing, sensing and driving to improve closed-loop performance in real-time control applications such as industrial motor drives, photovoltaic inverters and digital power supplies, electric vehicles and transportation, motor control, as well as sensing and signal processing.The C2000 family consists of both advanced performance MCUs and entry performance MCUs.

The TMS320F28335ZAYA devices are highly integrated, high-performance solutions for demanding control applications.

Features

- High performance static CMOS technology

- High-performance 32-bit CPU (TMS320C28x)

- 6-channel DMA controller (for ADC, McBSP, ePWM, XINTF, and SARAM)

- 16-bit or 32-bit external interface (XINTF)

- On-chip memory

- Boot ROM (8K × 16)

- Clock and system control

- GPIO0 to GPIO63 pins can be connected to one of the eight external kernel interrupts.

- Peripheral Interrupt Expansion (PIE) block supporting all 58 peripheral interrupts

- 128-bit security key/lock

- Enhanced control peripherals

- Serial Port Peripherals

- 12-bit ADC, 16-channel

- Up to 88 individually programmable multiplexed GPIO pins with input filters

- JTAG boundary-scan support

- Advanced debug features

- Development support includes

- Low power mode to save energy

- Byte order: Little end byte order

- Packaging: Lead-free, green package

- Temperature options:

- A: -40°C to 85°C (PGF, ZHH, ZAY, ZJZ)

- S: -40°C to 125°C (PTP, ZJZ)

- Q: -40°C to 125°C (PTP, ZJZ) (AEC Q100 certified for automotive applications)

Applications

- Advanced Driver Assistance Systems (ADAS)

- Medium/short range radar

- Building automation

- HVAC Motor Control

- Traction Inverter Motor Control

- Factory Automation & Control

- Automatic Sorting Equipment

- CNC Control

- Grid Infrastructure

- Central inverters

- String Inverters

- Hybrid, electric and powertrain systems

- Inverters and motor controls

- On-board chargers (OBC) and wireless chargers

- Motor Drives

- AC Input BLDC Motor Drives

- Servo Drive Control Modules

- Power Delivery

- Industrial AC/DC Power Supplies
