Sale, acquisition (NXP) MIMX8UX6AVLFZAC i.MX8X multi-core application processor - MPU 264MHz, 1.2GHz 1296-FCPBGA, if you need, please contact us!

Overview:

NXP i.MX 8X application processors extend the range of the i.MX 8 series, Features up to four Arm® Cortex-A35 cores, an Arm Cortex-M4F core for real-time processing, and an integrated Cadence® Tensilica® HiFi DSP for audio, voice, and speech processing. The i.MX 8X processor is part of the NXP EdgeVerse™ edge computing platform. The i.MX 8X processor family is highly integrated and supports picture, video, image processing, audio and voice functions, making it ideal for meeting efficient performance requirements that can be safely certified.

The I.ML 8X application processor is available in pin and power compatible 17mm2 and 21mm2 backchip Plastic Ball Grid Array (FCPBGA) packages in consumer/industrial grade (-40°C to +105°C) and automotive grade (-40°C to +125°C) temperature ratings.

Features:

• Up to four 1.2GHz Cortex-A35 processors

Provide a powerful, energy-efficient upgrade path for next generation solutions

• Multiple systems, one processor

High integration on a single chip, such as Cortex-A35 application core, Cortex-M4F real-time processing core, hardware-accelerated graphics and video, high-performance DSP, and more

• Optimized power

The Cortex-A35 core is turned off to reduce thermal system cost and power consumption, while the Cortex-M4F core remains active to perform low-level system monitoring tasks

• Optional Error Correction Code (ECC)

The i.MX 8X processor (with optional error correction codes (ECC)) is certified for Industrial Safety Integrity Level 3 (SIL 3) and is suitable for applications such as programmable logic controllers (PLCS), input/output (I/O) controllers, robot control and drones

• Advanced programmable security

Ensures best-in-class security with support for encryption standards such as AES, flash-free SHE, elliptic curve encryption, and key storage

• Multi-domain speech recognition

The integrated Tensilica HiFi 4 DSP provides features such as audio pre - and post-processing, keyword detection, and speech recognition for hands-free interaction

• Three separate content screens

Develop innovative multi-screen platforms by driving up to two 1080p screens (MIPI-DSI or LVDS) and a content-independent parallel WVGA display to reduce system costs

• Fully depleted insulator silicon (FD-SOI)

The i.MX 8X application processor uses 28nm FD-SOI, which significantly improves mean time between failures (MTBF) and reduces lock-in due to FD-SOI's inherent high resistance to soft errors

• Height is scalable

Easy conversion between the i.MX 8 series and i.MX 8X series, with a high level of software and hardware reuse across a wide range of product features

Target application:

CARS

Industrial vehicle

Advanced Industrial Human Machine Interface (HMI) and control

Robot

Building control

Medical care

network

Universal HMI solution
