SOT23, MAX6823WUK are Maxim's low voltage, microprocessor supervisory circuit chips.
MAX6823WUK Description:The MAX6823 is a low-voltage microprocessor (P) monitoring circuit that integrates voltage monitoring, watchdog timer, and manual reset inputs in a 5-pin SOT23 package. Microprocessor monitoring circuits significantly improve sy…
MAX6823WUK Description:
The MAX6823 is a low-voltage microprocessor (µP) monitoring circuit that integrates voltage monitoring, watchdog timer, and manual reset inputs in a 5-pin SOT23 package. Microprocessor monitoring circuits significantly improve system reliability and accuracy compared to individual ics or discrete components.
Each time the monitored voltage drops below its preset threshold, these devices set the reset signal and hold the signal on set for the shortest timeout period after the VCC rises above the threshold. In addition, the watchdog timer monitors for code execution errors. Manual reset with debuffing is also available.
The MAX6823 has a manual reset input and a watchdog timer. The device also has a push-pull/low-level active RESET.
MAX6823WUK Application:
Computer and controller
Accurate µP monitoring
Embedded controller
Intelligent instrument
Portable battery powered device
Set-top box
MAX6823WUK features:
Monitor +1.8V, +2.5V, +3.0V, +3.3V, +5.0V power supplies
Reset timeout delay: 140ms (min)
1.6s Watchdog timeout period
Manual reset input
Three reset output options
The push-pull low level is effectively RESET
Push-pull RESET
Open leakage low level effective RESET
Ensure effective reset at VCC = +1.0V
Not affected by fast negative VCC transients
No external components required
Small 5-pin SOT23 package
