Shenzhen Mingjiada Electronics Co., Ltd supplies and recycles [ST distributors] STM32H753IIK6 and STM32H753IIT6 STM32H7 high performance MCUs based on the high performance Arm® Cortex®-M7 32-bit RISC core.

Description:

The STM32H753IIK6 and STM32H753IIT6 STM32H7 MCUs support a full set of DSP instructions and a memory protection unit (MPU) for enhanced application security.

The MCUs feature high-speed embedded memory with up to 2MB of dual-zone Flash, 1 MB of RAM (including 192 KB of TCM RAM, 864 KB of user SRAM and 4 KB of backup SRAM). In addition, the device features a variety of enhanced I/O and peripherals connected to the APB bus, AHB bus, 2x32-bit multi-AHB bus matrix, and a multi-layer AXI interconnect supporting internal and external memory access.

Features:

Core

32-bit Arm® Cortex®-M7 core with double-precision FPU and L1 cache: 16KB data and 16KB instruction cache.

Supports single access to one cache line from 256-bit embedded flash; up to 400 MHz, MPU, 856 DMIPS/2.14 DMIPS/MHz (Dhrystone 2.1) and DSP instructions

Memory

Up to 2Mbyte Flash with simultaneous read/write capability

1MB of RAM: 192KB of TCM RAM (including 64KB of ITCM RAM + 128KB of DTCM RAM for storing time-sensitive critical programs or data), 864KB of user SRAM, and 4KB of backup domain SRAM

Dual-mode Quad-SPI memory interface running at up to 133MHz

Flexible external memory controller with up to 32-bit data bus: SRAM, PSRAM, SDRAM/LPSDR SDRAM, NOR/NAND Flash clocked at up to 133MHz in synchronous mode

CRC calculation unit

Security

ROP, PC-ROP, active tampering

General purpose inputs/outputs

Up to 168 I/O ports with interrupt capability

Fast I/O running at up to 133 MHz

Up to 164 5V tolerant I/Os

Reset and power management

3 independent power domains that can be independently clocked gated or switched off to maximise power efficiency::

D1: High performance peripherals enabling high bandwidth

D2: Communication peripherals and timers

D3: Reset/clock control/power management

1.62V to 3.6V application power and I/O

POR, PDR, PVD and BOR

Dedicated USB power supply with embedded 3.3V internal regulator to power internal PHY

Embedded voltage regulator (LDO) with configurable scalable outputs to power digital circuits

Voltage regulation in run and stop modes (5 configurable ranges)

Backup voltage regulator (~0.9V)

Reference voltage/VREF+ for analogue peripherals

Low power modes: sleep, stop, standby and VBAT support for battery charging

Low power consumption

Total current consumption down to 4μA

Clock management

Internal oscillators: 64kHz HSI, 48MHz HSI48, 4MHz CSI, 40kHz LSI

External oscillators: 4MHz - 48MHz HSE, 32.768kHz LSE

3 PLLs with fractional mode (1 for system clock, 2 for core clock)
