3.3V, ±15kV Interface IC ISL3332IAZ-T RS-422/RS-485 Full Version Transceiver

3.3V, ±15kV Interface IC ISL3332IAZ-T RS-422/RS-485 Full Version Transceiver

Source:our siteTime:2023-03-14Views:

The ISL3332 is a dual port interface IC where each port can be independently configured as a single RS-485/422 transceiver, or dual (2 Tx, 2 Rx) RS-232 transceivers. When both ports are set to the same mode, two RS-485/RS-422 transceivers or four RS-2…

The ISL3332 is a dual port interface IC where each port can be independently configured as a single RS-485/422 transceiver, or dual (2 Tx, 2 Rx) RS-232 transceivers. When both ports are set to the same mode, two RS-485/RS-422 transceivers or four RS-232 transceivers are available.


Supplier: Mingjiada Electronics Co.

Product Model:ISL3332IAZ-T

Brand：Renesas

Year: 23+

Package: 28-SSOP

Description: RS-422/RS-485 Interface IC DL 3 3V MULTIPROTO TRANSC 2 8LD SSOP


Features

-15kV (HBM) ESD protected bus pins (RS-232 or RS-485)

-Operates on a single 3.3V power supply

-Two independent ports, each user can choose between RS-232 (2 transceivers) or RS-485/RS-422 (1 transceiver)

-True flow pins simplify board layout

-Lead-free (RoHS compliant)

-Full fault protection (open/short) in RS-485/422 mode Rx

-Loopback mode contributes to board self-test function

-High speed: 20Mbps

-Rotary rate limit: 460kbps

-Rotary rate limit: 115kbps

-Fast RS-232 data rate: up to 400kbps

-Small charge pump cover: 4 x 0.1µF

-Low current shutdown mode: 35µA


Applications

-Gaming applications (e.g. slot machines)

-Single board computers

-Factory automation

-Security networks

-Industrial/process control networks

-Level converters (e.g. RS-232 to RS-422)

-Point-of-sale devices

-Dual channel RS-485 interface


Company homepage: www.hkmjd.com
