TA2-32N-Q-T/R is a side-push tactile switch manufactured by Diptronics Manufacturing Inc. Its distinctive feature is that the button is actuated by pressing from the side, rather than the conventional top-down vertical press. This design is frequently employed in applications where functional keys need to be positioned on the side of equipment but internal height space is severely constrained.

Contact Configuration: Classified as an SPST (Single Pole Single Throw) switch, representing the simplest switch type with only two states: ‘ON’ and ‘OFF’.

Packaging: Supplied in Cut Tape packaging for seamless integration with automated pick-and-place soldering processes.

TA2-32N-Q-T/R Specifications

Manufacturer: Diptronics

Product Type: Tactile Switch

Switch Type: Side-Actuated

Contact Configuration: SPST (Single Pole Single Throw)

Dimensions: 4.65mm × 7mm

Actuation Force: 160 gf (Newton-force)

Electrical Rating: DC 12V, 50mA

Travel: 0.25mm

Mounting Method: Right-angle mounting, solder pins

Operating Temperature Range: -25°C to +70°C

Packaging: Cut tape

Colour: Brown
