Commodity Model:NN03-320

Trade Name:RF Antenna

Brand:Ignion

Particular Year:22+

Package:SMD

Delivery Date:New and Original

Stock: 2500pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Ignion
Model
NN03-320
Package
SMD
Describe
RF antenna 1500-10600MHz

Product Description

The Ignion NN03-320 DUO mXTEND™ antenna amplifier is designed to provide multi-band performance for wireless devices. This feature enables global coverage by supporting multiple communication standards, including GSM, UMTS, 4G, BLUETOOTH®, Wi-Fi® dual-band, and LTE. These antenna amplifiers are manufactured using glass epoxy substrates and offer omnidirectional radiation patterns and linear polarisation. The Ignion NN03-320 DUO mXTEND antenna amplifier is suitable for mobile phones, smart devices, personal electronics, USB adapters, utility meters, and more.


NN03-320 Features

High efficiency

Compact design

Easy to use (plug-and-play)

Dual mounting system, can be installed at the corner or centre edge of the device

Multi-band support, compatible with global standards

Off-the-shelf standard product, no customisation required


NN03-320 Specifications

Manufacturer: Ignion

Product Category: Antenna

Product Type: Multiprotocol Antennas

Product: PCB Antennas

Type: Passive Antenna

Minimum Frequency: 1.5 GHz

Maximum Frequency:    10.6 GHz

Protocol - Bluetooth, BLE - 802.15.1:    Bluetooth

Protocol - Cellular, Nbiot, LTE:    5G, Cellular (NBIoT, LTE)

Protocol - GPS, GLONASS:    GNSS

Protocol - Sub GHz:    IoT

Mechanical Form:    Chip

Type:    Rectangular

Gain:    -1.1 dBi, -1 dBi, -1 dBi, -0.9 dBi, 1.6 dBi, 1.8 dBi, 1.1 dBi, 1.8 dBi, 2.6 dBi, 2.3 dBi, 3.6 dBi

Impedance:    50 Ohms

VSWR:    3:1

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Electrical Type:    Monopole

Band Count:    12 Band

Mounting Style:    PCB Mount

Termination Type:    SMD/SMT

Centre Frequency:    1561 MHz, 1575 MHz, 1602 MHz, 2450 MHz, 3600 MHz, 3950 MHz, 5387.5 MHz, 7250 MHz, 8300 MHz

Applications:    Tracking devices, wearable devices, gaming devices, IoT-5G modules

Associated Products

Model

Brand

Package

Quantity

Describe

NN03-310

Ignion

SMD

1200

RF antenna 400-8000MHz

BGSA11GN10E6327XTSA1

INFINEON

10-XFQFN

2000

Dual Single Pole Single Throw Antenna Tuning Switch

BGSA149M2N10E6327XTSA1

INFINEON

10-XFQFN

2000

Ultra low OFF capacitance antenna tuning SP4T

YEMN926J1A

Quectel

SMD

2000

GNSS Dome RF Antenna, SMA Male Screw Mount

BGSA149M2N10

INFINEON

TSNP-10-9

1000

Ultra low turn-off capacitor antenna tuning SP4T TSNP-10-9
