Trade Name:Board-to-Board Connector
Brand:Samtec
Particular Year:25+
Package:300POS
Delivery Date:New and Original
Stock: 1300pcs
SEAF-50-01-L-06-1-RA-GP-TR is a 300-position high-density array connector featuring a right-angle open-pin design with a pitch of 0.050 inches (1.27 mm). Its design is tailored to meet high-speed signal transmission requirements, supporting performance up to 56 Gbps, and is suitable for various single-ended or differential pair configurations. The connector employs a durable Edge Rate® terminal system, delivering exceptional signal integrity and ensuring reliability and stability in high-speed applications.
The high-density design of SEAF-50-01-L-06-1-RA-GP-TR maximises design and routing flexibility, enabling it to accommodate diverse power, signal, or grounding requirements. Its gold-plated surface-mount interface ensures excellent electrical performance and durability, while supporting multiple stacking height options to meet the requirements of different application scenarios.
Product specifications — SEAF-50-01-L-06-1-RA-GP-TR
Pin count: 300P
Pitch: 0.050 inches (1.27 mm)
Mounting method: Surface mount, right angle
Number of rows: 6
Connector type: High-density array, female
Contact surface treatment: Gold-plated
Contact surface treatment thickness: 10.0μin (0.25μm)
Mating stack height: Optional
Series: SEARAY™ SEAF
Product Features — SEAF-50-01-L-06-1-RA-GP-TR
High-density design: Provides up to 300 pins in a limited space, meeting complex circuit connection requirements while supporting multiple configurations to enhance design flexibility.
High-speed signal transmission: Utilises the Edge Rate® terminal system, supporting data transmission rates of up to 56 Gbps, ensuring signal integrity and reliability, suitable for high-speed communication and data processing applications.
Multiple Configuration Options: Offers different stacking height options to accommodate various design requirements, and supports single-ended or differential pair configurations, as well as different power, signal, or grounding needs.
Low Insertion and Withdrawal Force: Facilitates connection and disconnection while ensuring connection stability, simplifying device assembly and maintenance processes.
High reliability: Manufactured using high-quality materials and subjected to rigorous quality control and testing, it offers excellent electrical performance and mechanical stability, ensuring reliable long-term operation in harsh environments.
Good compatibility: Compatible with a wide range of high-speed communication and data processing devices, it can be widely applied in high-speed communication, data processing, military, and aerospace fields.
