Trade Name:Board To Board Connectors
Brand:Samtec
Particular Year:25+
Package:200POS
Delivery Date:New and Original
Stock: 3000pcs
SEAF-40-05.0-L-05-2-A-K-TR: SEARAY™ Open Terminal Array .050’ (1.27 mm) Pitch Connector
Model: SEAF-40-05.0-L-05-2-A-K-TR
Series: SEARAY™ SEAF
Package: 200POS
Type: Board-to-Board Connector
Product Details: .050’ SEARAY™ High Speed High Density Terminal Open Terminal Array Receptacle
Overview:
SEARAY™ is an open terminal array .050’ (1.27 mm) pitch connector.SEARAY™ provides up to 500 terminals to maximise design and wiring flexibility for single-ended or differential pair configurations as well as power, signal or ground.SEARAY™ uses the Edge Rate® termination system, which is specifically designed for connectors that require a high docking cycle and 56 The SEAF features SureCoat™ palladium-nickel and flash gold plating and is Extended Life Product™ certified to withstand 5.000 cycles and 150º operating temperature.
SEAF-40-05.0-L-05-2-A-K-TR Specifications:
Connector Type: High Density Array
Number of Positions: 200
Pitch: 0.050’ (1.27mm)
Number of rows: 5
Mounting Type: Surface Mount
Features: Board Guide, Pick and Place
Contact Finish: Gold Plated
Contact Finish Thickness: 10.0µin (0.25µm)
Joint Stacking Height: 7mm, 8mm, 8.5mm, 11.5mm, 12mm, 14mm, 16mm, 18mm
Height on Board: 0.199’ (5.05mm)
Model
Brand
Package
Quantity
Describe
Samtec
320POS
1320
320-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
240POS
1240
240-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
300POS
1300
300-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
180POS
1180
180-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
300POS
1300
300-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
180POS
1180
180-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
180POS
1180
180-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
240POS
1240
240-position connector, high-density array, female, surface mount, right angle, gold-plated
Samtec
500POS
1500
500-position connector, high-density array, male, surface mount, right angle, gold-plated
Samtec
240POS
1240
240-position connector, high-density array, male, surface mount, gold-plated
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
