The SEAM-30-02.0-L-10-2-A-K-TR is Samtec's SEARAY™ series connector, featuring 300 pin locations on a 0.050-inch (1.27mm) pitch in a high-speed, high-density, open-pin-field array connector. Designed to meet the demands of high-speed signalling, the connectors support up to 500 pins and offer great wiring flexibility for single-ended and differential pair configurations, as well as power, signal or ground pinning requirements.

SEAM-30-02.0-L-10-2-A-K-TR Product Features

High Density Design: 300 pin locations with 1.27mm pitch for high speed, high density connections.

Low-profile design: Space-saving for thin and light devices.

Contact System: Rugged Edge Rate® contact system ensures reliable electrical connection and mechanical stability.

High voltage and current carrying capacity: Rated current up to 2.7A, rated voltage up to 240VAC.

Excellent electrical performance: Supports high-speed signal transmission up to 56Gbps PAM4 performance.

Compliance: RoHS compliant, supports lead-free soldering.

Package: Surface mount for automated production.

SEAM-30-02.0-L-10-2-A-K-TR Product Attributes

Product Category: Board-to-Board and Mezzanine Connectors

Product: Headers

Number of Positions: 300 Position

Pitch: 1.27 mm (0.05 in)

Number of Rows: 10 Row

Termination Type: Solder

Mounting Angle: Vertical

Stacking Height: 7 mm, 8 mm, 8.5 mm, 9.5 mm

Current Rating: 2.7 A

Voltage rating: 240 VAC

Maximum data rate: 56 Gbps

Minimum Operating Temperature: - 55 C

Maximum operating temperature: + 125 C

Contact Plating: Gold

Contact Material: Copper Alloy

Case Material: Liquid Crystal Polymer (LCP)

Series: SEAM

Applications: Power, Signal

Data Rate: 56 Gbps
