The STM32G070CBT6TR is a 32-bit microcontroller from STMicroelectronics based on the Arm® Cortex®-M0+ core, featuring high performance, low power consumption and a rich peripheral interface for a wide range of embedded applications.

STM32G070CBT6TR Product Features

High-performance processor: The 32-bit Arm Cortex-M0+ processor operates at up to 64MHz, providing efficient computing power.

Large storage capacity: 128KB of flash memory and 36KB of SRAM to meet the storage needs of complex applications.

Low-power design: With an operating voltage range of 2.0V to 3.6V and multiple low-power modes such as sleep, stop, and standby, it can effectively reduce power consumption.

Rich peripheral interfaces: Including multiple communication interfaces (e.g. I2C, SPI, USART, etc.), timer, ADC and other peripheral functions to support a variety of application scenarios.

High-precision ADC: Equipped with a 12-bit analogue-to-digital converter (ADC) with a conversion speed of 0.4μs and support for up to 16 external channels, the ADC is suitable for high-precision analogue signal acquisition.

Various oscillator options: Supports 4 to 48MHz crystal oscillator, 32kHz crystal oscillator with calibration, and internal 16MHz RC oscillator, providing flexible clock selection.

Flexible I/O functions: Up to 59 fast I/Os, all mapped to external interrupt vectors, and multiple 5V tolerant I/Os to suit different circuit design requirements.

STM32G070CBT6TR Technical Parameters

CPU core: Arm Cortex-M0+.

Maximum CPU frequency: 64MHz

Programme memory capacity: 128KB

Programme memory type: FLASH

Data memory type: SRAM

Data storage capacity ：36KB

Number of I/O ports: 43

ADC: 12-bit, up to 16 channels

Operating voltage: 2V to 3.6V

Operating temperature range: -40°C to 85°C

Package: LQFP-48

STM32G070CBT6TR Application Areas

Industrial automation: Can be used in motor control, sensor data acquisition and other industrial equipment to achieve precise control and monitoring.

Smart Home ：Suitable for the control of smart home appliances, such as smart lights, smart curtains, etc., providing low-power, high-performance solutions.

Internet of Things (IoT) devices: applicable to various IoT nodes, such as environmental monitoring sensors, smart gateways, etc., supporting low-power operation and data acquisition and transmission.

Consumer electronics: Can be used in portable electronic products, such as electronic dictionaries, smart watches, etc., to meet the demand for high performance and low power consumption.
