The STM32L031C6U6 is an ultra-low power 32-bit microcontroller designed on the Arm® Cortex®-M0+ core in a 48-pin UFQFPN package (7x7mm). The device integrates 32KB Flash program memory, 8KB SRAM and 1KB data EEPROM, and operates up to 32MHz, optimised for power-sensitive applications.

STM32L031C6U6 Product Attributes

Product Category: ARM Microcontrollers - MCUs

Family: STM32L031C6

Mounting Style: SMD/SMT

Package / Case: UFQFPN-48

Core: ARM Cortex M0+

Programme memory size: 32 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 32 MHz

Number of inputs/outputs: 38 I/Os

Data RAM size: 8 kB

Supply voltage - min: 1.8 V

Supply voltage - max: 3.6 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Analogue supply voltage: 1.65 V to 3.6 V

Data Ram Type: RAM

Data ROM size: 1 kB

Data Rom Type: EEPROM

Interface Type: I2C, LPUART, SPI, USART

Humidity Sensitivity: Yes

Number of ADC channels: 10 Channel

Number of Timers/Counters: 4 Timer

Processor Family: STM32L031

Product: MCUs

Product Type: ARM Microcontrollers - MCUs

Programme Memory Type: Flash

Factory Package Quantity: 1560

Sub Category: Microcontrollers - MCUs

Trade Name: STM32

Watchdog Timer: Watchdog Timer, Windowed

Unit weight: 99.700 mg

STM32L031C6U6 with its ultra-low power consumption and high integration features is widely used in:

Portable medical devices

Industrial sensors and controllers

Smart home devices

Consumer electronics

IoT terminal nodes

Battery-powered remote monitoring devices
